Heating Compact 15-70/130

Part Number: COMPACT15

The Archergas® Heating Compact is a Domestic Heating Pump that produces a maximum head of 7 meters and has a standard 1 1/2" threaded connection. It has 10 modes of operation and a 130mm port to port size making it ideal for the replacement of existing Heating Pumps in domestic heating systems and for new installations. The COMPACT15® is also perfect for integration into appliances like boilers or heat pumps. As a semi-automatic modulating circulator, the Heating Compact is able to modulate flow based on system demand. As with all Archergas® circulators, it is fully ERP compliant with an impressive energy efficiency index rating of less than 0.20. It also comes with a 5 year guarantee and can be used as a direct replacement for a number of other models, some of which are listed below:

Replaces:

Make | Model

Grundfos | UP, UPS 4m, 5m, 6m, UPSD, UPS2, UPM3 & UPS3

Lowara | Ecocirc, Ecocirc Basic & Premium 25-40 & 25-6 (130)

Wilo | Yonos Pico 15/1-6-130, Yonos Para 25/6 & 25/7, Gold, Gold Star, Gold 50, 60 & RS25

Embrass Peerless | Eclipse CFA 25-50 & 60-130

DAB | VA55/130, VA65/130, Evotron 60/130, Evosta 40/70

Circulating Pumps | CP50, CP60 & Myson LA, SD, CP53 & CP63

BritTherm | Domestic Standard, Domestic Pro & Black Edition Pro 15-60/130

Salus | MP100A & MP200A

Boiler M8 | RS25/6G-130, RS25/6EAR-130, GPA25-6 II AC & GPD25-6S-130

Stuart Turner | ST 15/60 (130)

Antares | Type S40 to S60, Alfamax RS & AS 15/40 to RS & AS 25/60 (130)

Tower | APUMP+

Specification

Part Number: COMPACT15

Connection Size: 1 ½”

Port to Port Distance: 130mm

Maximum Head: 7 Meters

Maximum Flow Rate: 65 Litres Per Minute

Maximum System Pressure: 10 Bar

Speed Control: 10 Modes

CE/UKCA Approved: Yes

Energy Efficiency Index (EEI): ≤ 0.20

Protection Class: IP44

Temperature Class: TF95ºC

Insulation Class: F

Supplied With: Rubber Washers x2 & Quick Connect Adaptor x1

Material: Cast Iron

Colour: Jet Black

Weight: 1.8kg

The benchmark for the most efficient circulators is EEI ≤ 0.20

COMPACT15® is a registered trademark owned by Archergas Limited
