Heating Standard 15-60/130

Part Number: ST15

The Archergas® Heating Standard produces a maximum head of just over 6 meters with a standard 1 1/2" threaded connection. As with all Archergas® circulators, it is fully ERP compliant with an impressive energy efficiency index rating of less than 0.20. The ST15 is a standalone heating circulator with 4 modes of control and a standard 130mm port to port size. The ST15® is suitable for radiators, underfloor heating, cooling, solar, recirculation (non-potable) and air source heat pump systems. Due to our quality focused approach to manufacturing and our use of high end component materials, this circulator is resistant to condensation, corrosion, high pressure and high temperatures. It also comes with a 5 year guarantee and can be used as a direct replacement for a large number of other models, some of which are listed below:

Replaces:

Make | Model

Grundfos | UP, UPS 4m, 5m, 6m, UPSD, UPS2, UPM3 & UPS3

Lowara | Ecocirc, Ecocirc Basic & Premium 25-40 & 25-6 (130)

Wilo | Yonos Pico 15/1-6-130, Gold, Gold Star, Gold 50, 60 & RS25

Embrass Peerless | Eclipse CFA 25-50 & 60-130

DAB | VA55/130, VA65/130, Evotron 60/130, Evosta 40/70

Circulating Pumps | CP50, CP60 & Myson LA, SD, CP53 & CP63

BritTherm | P1 25-6/130 & Domestic Pro 15-60/130

Salus | MP100A & MP200A

Boiler M8 | RS25/6G-130, RS25/6EAR-130, GPA25-6 II AC & GPD25-6S-130

Stuart Turner | ST 15/60 (130)

Antares | Type S40 to S60, Alfamax RS & AS 15/40 to RS & AS 25/60 (130)

Pegler | Terrier TC5 & TC6

Circulating Pumps (Myson) | CP50, CP60 & Myson LA, SD, CP53 & CP63

Flomasta | 25-5-130 & 25-6-130

Smiths | ES2 25-60/130

IBO | OHI, BETA, MAGI & NOVA 25-60/130

SMC | Cadet, Commodore & Comet 130

Katsu | 151711

Ferro | GPA 25-6 II

Euramo | MXL 130, D, Gold, Solid Gold, Goldstar

Arcus | 356R & 136EA

Jass Ferry | KBD20-6S-130 & KBD25-6S-130

Primaflow | CP5, CP6, CPE6 & HE-6

Tucson | GPD25-5S & RS256EA

CBS | CBS 60 & CBS Intel 15-60/130

Adlink | Type 15-60/130 & 25-60/130

Anchor Pumps | Desgee AC 15-130

Bacoeng | DN40-6G

Trident | WPB 25-6

WSTN | WRS 25-60/130

FHS | LPS40-6S/130

Tower | APUMP+

Specification

Part Number: ST15

Connection Size: 1 ½”

Port to Port Distance: 130mm

Maximum Head: 6 Meters

Maximum Flow Rate: 65 Litres Per Minute

Maximum System Pressure: 10 Bar

Energy Efficiency Index Rating (EEI): ≤ 0.20

Speed Control: 4 Modes

CE/UKCA Approved: Yes

Protection Class: IP44

Temperature Class: TF95ºC

Insulation Class: F

Supplied With: Rubber Washers x2

Material: Cast Iron

Colour: Jet Black

Weight: 2.0kg

The benchmark for the most efficient circulators is EEI ≤ 0.20

ST15® is a registered trademark owned by Archergas Limited

This standalone circulator is not for head changes or use inside boilers
