Hot Water Standard 15-60/130 (WRAS Approved Bronze Pump)
Part Number: DHW15
*WRAS Approved Bronze Pump
UK Registered Design Certificate
EU Registered Design Certificate
UK Registered Trademark Certificate
The Archergas® Hot Water Standard is a WRAS Approved Domestic Hot Water Pump (Secondary Return/Bronze Pump) that produces a maximum head of 6 meters and has a standard 1 1/2" threaded connection. As with all Archergas® circulators, it is fully ERP compliant with an impressive energy efficiency index rating of less than 0.20. The DHW15® is a standalone circulator with 4 modes of control and a 130mm port to port size making it ideal for the replacement of existing Hot Water Pumps in domestic hot water systems, as well as new installations. Due to our quality focused approach to manufacturing and our use of high end component materials, this circulator is resistant to condensation, corrosion, high pressure and high temperatures. It also comes with a 5 year guarantee and can be used as a direct replacement for a large number of other models, some of which are listed below:
Replaces:
Make | Model
Grundfos | UPS 15-50N (130)
Wilo | SB30/SB30G, SB5 &SB60
DAB | EVO VS 65/150 B
BritTherm | Bronze Edition 15-60/130 & Silver Edition 15-60/130
Tower | BRZPUMP
Stuart Turner | 15/60B DHW
Circulating Pumps | SE20B & SE60B
IBO | OHI15-60/130
IMP Pumps | SAN 25/60-130 & NMT SAN PLUS
Specification
Part Number: DHW15
Connection Size: 1 ½”
Port to Port Distance: 130mm
Maximum Head: 6 Meters
Maximum Flow Rate: 65 Litres Per Minute
Maximum System Pressure: 10 Bar
CE/UKCA Approved: Yes
WRAS Approved: Yes
Energy Efficiency Index Rating (EEI): ≤ 0.20
Speed Control: 4 Modes
Protection Class: IP44
Temperature Class: TF95ºC
Insulation Class: F
Supplied With: Rubber Washers x2 & Quick Connect Adaptor x1
Material: Stainless Steel
Colour: Silver
Weight: 2.0kg
The benchmark for the most efficient circulators is EEI ≤ 0.20
DHW15® is a registered trademark owned by Archergas Limited
This standalone circulator is not for head changes or use inside boilers
