Light Commercial Standard 25-80/180
Part Number: LIGHT25
UK Registered Design Certificate
EU Registered Design Certificate
UK Registered Trademark Certificate
The Archergas® Light Commercial Standard produces a maximum head of just over 8 meters with a standard 1 1/2" threaded connection. As with all Archergas® circulators, it is fully ERP compliant with an impressive energy efficiency index rating of less than 0.21. The pump has 4 modes of control and a standard 180mm port to port size. The LIGHT25® is suitable for radiators, underfloor heating, cooling, solar, recirculation (non-potable) and air source heat pump systems. Due to our quality focused approach to manufacturing and our use of high end component materials, this circulator is resistant to condensation, corrosion, high pressure and high temperatures. It also comes with a 5 year guarantee and can be used as a direct replacement for a large number of other models, some of which are listed below:
Replaces:
Make | Model
Grundfos | UP, UPS, UPS2, Magna (25-55, 25-70 & 25-80)
Wilo | Yonos Pico 25/1-8-180, Yonos Para 25/7-180
DAB | Evotron 80/180 & Evoplus 80/180
Salus | MP280A
Stuart Turner | ST 25/80 (180)
Lowara | Ecocirc, Ecocirc Basic, Premium XL Plus 25-8 (180)
Adlink | Type 25-60/180 & 25-80/180
Antares | Type S70, S80, S89, Alfamax RS 25/60 & Alfamaior RS 25/80 (180)
BritTherm | Light Commercial Pro 25-80/180
Boiler M8 | RS25/8G-180 & RS25/8EA
IBO | OHI 25-80/180, MAGI 25-60/180 & 25-40/180, BETA 25-80/180
Polaris Gold | POL-WPG8M
Specification
Part Number: LIGHT25
Connection Size: 1 ½”
Port to Port Distance: 180mm
Maximum Head: 8 Meters
Maximum Flow Rate: 115 Litres Per Minute
Maximum System Pressure: 10 Bar
Energy Efficiency Index Rating (EEI): ≤ 0.21
CE/UKCA Approved: Yes
Speed Control: 4 Modes
Protection Class: IP44
Temperature Class: TF95ºC
Insulation Class: F
Supplied With: Rubber Washers x2 & Quick Connect Adaptor x1
Material: Cast Iron
Colour: Jet Black
Weight: 2.3kg
The benchmark for the most efficient circulators is EEI ≤ 0.20
LIGHT25® is a registered trademark owned by Archergas Limited
This standalone circulator is not for head changes or use inside boilers
